Servo Gearhead - Output Shaft
















Servo Gearhead Output Shaft

Premium Type
(Helical Gear)
 Precision  Type
(Helical Gear)
  Precision Type
(Spur Gear)
Standard Type
(Spur Gear)
Primary Type
(Spur Gear)
planetary gearhead, gear reducer, gearbox, 行星減速機 planetary gearhead, precision, 行星式減速機, 行星減速機, 齒輪減速機 planetary gearhead, gear reducer, 行星減速機 planetary gearhead, gear reducer, 行星減速機 planetary gearhead, gear reducer, 行星減速機 planetary gearhead, gear reducer, 行星減速機 planetary gearhead, gear reducer, 行星減速機 planetary gearhead, gear reducer, 行星減速機 planetary gearhead, gear reducer, 行星減速機 planetary gearhead, gear reducer, 行星減速機 planetary gearhead, gear reducer, 行星減速機 planetary gearhead, gear reducer, 行星減速機
PHL
Series
PGH
Series
PUL
Series
PGLH
Series
PGL
Series
PGC
Series
PGE
Series
PAC
Series
PAE
Series
PAN
Series
PNS
Series
PGS
Series
PBC
Series
PBE
Series

Servo Gearhead Product Features
  Series Features
Premium Type
(Helical Gear)
planetary gearhead, gear reducer, gearbox, 行星減速機
PHL Series
Nominal Output Torque
T2N:11Nm - 150Nm
Ratio
Single Stage:3/ 4/ 5/ 6/ 7/ 8 /9 /10
Double Stage:15/ 20/ 25/ 30/ 35/ 40/ 45/ 50/ 60/ 70/ 80/ 90/ 100
Low Backlash
Single Stage:≦1 arcmin/ ≦3 arcmin/ ≦5 arcmin
Double Stage:≦3 arcmin/ ≦5 arcmin/ ≦7 arcmin
High Efficiency
Single Stage:≧97%
Double Stage:≧94%
Low Noise
56~60 dBA/1m
planetary gearhead, precision, 行星式減速機, 行星減速機, 齒輪減速機
PGH Series
Nominal Output Torque
 T2N11Nm - 2000Nm

Ratio
 Single Stage:3/ 4/ 5/ 6/ 7/ 8 /9 /10

 Double Stage:15/ 20/ 25/ 30/ 35/ 40/ 45/ 50/ 60/ 70/ 80/ 90/ 100
Low Backlash

Single Stage:≦1 arcmin/ ≦3 arcmin/ ≦5 arcmin
 Double Stage:≦3 arcmin/ ≦5 arcmin/ ≦7 arcmin
High Efficiency
 Single Stage:≧97%
 Double Stage:≧94%
Low Noise
 56~70 dBA/1m
planetary gearhead, gear reducer, high radial load, 高徑向負載, 高軸向負載, 行星減速機
PUL Series
Nominal Output Torque
 T2N:37Nm - 2000Nm
Ratio
 Single Stage:3/ 4/ 5/ 6/ 7/ 8 /9 /10
 Double Stage:15/ 20/ 25/ 30/ 35/ 40/ 45/ 50/ 60/ 70/ 80/ 90/ 100
Low Backlash

Single Stage:≦1 arcmin/ ≦3 arcmin/ ≦5 arcmin
 Double Stage:≦3 arcmin/ ≦5 arcmin/ ≦7 arcmin
High Efficiency
 Single Stage:≧97%
 Double Stage:≧94%
Low Noise
 58~70 dBA/1m
Precision Type
(Helical Gear)
planetary gearhead, gear reducer, 行星減速機
PGLH Series
Nominal Output Torque
 T2N:11Nm - 300Nm
Ratio
 Single Stage:3/ 4/ 5/ 6/ 7/10
 Double Stage:15/ 20/ 25/ 30/ 35/ 40/ 45/ 50/ 70/ 100
Low Backlash

Single Stage:≦5 arcmin/ ≦7 arcmin
 Double Stage:≦7 arcmin/ ≦9 arcmin
High Efficiency
 Single Stage:≧97%
 Double Stage:≧94%
Low Noise
 58~65 dBA/1m
Precision Type
(Spur Gear)
planetary gearhead, gear reducer, 行星減速機
PGL Series
Nominal Output Torque
 T2N:9.8Nm - 1670Nm
Ratio
 Single Stage:3/ 4/ 5/ 6/ 7/ 8 /9 /10
 Double Stage:15/ 20/ 25/ 30/ 35/ 40/ 45/ 50/ 60/ 70/ 80/ 90/ 100
Low Backlash

Single Stage:≦3 arcmin/ ≦5 arcmin/ ≦7 arcmin
 Double Stage:≦5 arcmin/ ≦7 arcmin/ ≦9 arcmin
High Efficiency
 Single Stage:≧96%
 Double Stage:≧92%
Low Noise
 60~75 dBA/1m
planetary gearhead, gear reducer, 行星減速機
PGC Series
Nominal Output Torque
 T2N:10.1Nm - 1670Nm
Ratio
 Single Stage:3/ 4/ 5/ 7/ 10
 Double Stage:15/ 20/ 25/ 30/ 35/ 40/ 45/ 50/ 70/ 100
Low Backlash

Single Stage:≦3 arcmin/ ≦5 arcmin/ ≦7 arcmin
 Double Stage:≦5 arcmin/ ≦7 arcmin/ ≦9 arcmin
High Efficiency
 Single Stage:≧95%
 Double Stage:≧92%
Low Noise
 60~75 dBA/1m
Standard Type
(Spur Gear)
planetary gearhead, gear reducer, 行星減速機
PAC Series
planetary gearhead, gear reducer, 行星減速機
PAE Series
Nominal Output Torque
 T2N:8Nm - 270Nm
Ratio
 Single Stage:3/ 4/ 5/ 7/ 9/ 10
   Double Stage:15/ 20/ 25/ 30/ 35/ 40/ 45/ 50/ 70/ 100
Low Backlash
 Single Stage:≦6 arcmin
   Double Stage:≦8 arcmin
High Efficiency
 Single Stage:≧95%
   Double Stage:≧90%
Low Noise
 61~67 dBA/1m
planetary gearhead, gear reducer, 行星減速機
PAN Series
PNS Series
Nominal Output Torque
 T2N:8Nm - 215Nm
Ratio
 Single Stage:3/ 4/ 5/ 7/ 9/ 10
   Double Stage::15/ 20/ 25/ 35/ 45/ 50/ 70/ 90/ 100
 Three Stage125/ 175/ 225/ 245/ 315/ 405/567/ 729/ 1000
Low Backlash
 Single Stage:≦6 arcmin
 Double Stage:≦8 arcmin
 Three Stage≦12 arcmin
High Efficiency
 Single Stage:≧95%
 Double Stage:≧90%
 Three Stage:≧85%
Low Backlash
 60~67 dBA/1m
PGS Series
Nominal Output Torque
 T2N:8Nm - 255Nm
Ratio
 Single Stage:3/ 4/ 5/ 7/ 9
 Double Stage:15/ 20/ 25/ 35/ 40/ 45/ 49/ 63/ 81
Low Backlash

Single Stage:≦6 arcmin
 Double Stage:≦8 arcmin
High Efficiency
 Single Stage:≧95%
 Double Stage:≧90%
Low Noise
 61~67 dBA/1m
Primary Type
(Spur Gear)
planetary gearhead, gear reducer, 行星減速機
PBC Series
planetary gearhead, gear reducer, 行星減速機
PBE Series
Nominal Output Torque
 T2N:10.1Nm - 1670Nm
Ratio
 Single Stage:3/ 4/ 5/ 7/ 9
 Double Stage:15/ 20/ 25/ 35/ 45/ 49/ 63/ 81
 Triple Stage:125/ 175/ 225/ 245/ 315/ 405/ 567/ 729

Low Backlash

Single Stage:≦7 arcmin/ ≦8 arcmin/ ≦9 arcmin
 Double Stage:≦9 arcmin/ ≦10 arcmin/ ≦12 arcmin
 Triple Stage:≦12 arcmin/ ≦15 arcmin
High Efficiency
 Single Stage:≧95%
 Double Stage:≧90%
 Triple Stage:≧85%

Low Noise
 62~67 dBA/1m
